Coating systems

The right solution for every coating need:
Coatema's offers more than 35 different systems for coating and printing. The main designs are shown in sketch form here.

When it comes to coating tasks, printing processes and plant design, we have the ideal coating module for films, textiles, papers, non-woven materials and more. We can cater for continuous coating/printing and the coating/printing and lamination of single parts made from glass, metal, cardboard and other materials.

Coatema offers a wide range of application systems that can be used for the most demanding coating and printing processes. We also carry out ongoing research and development in order to improve our coating and printing systems and develop new ones.



Coatema Auftragssysteme Coatingprinting systems



Our main coating systems are:



Doctor blade system

Coatema Knife rakel system RGB

Coating
Doctor blade on roller: 10 – 1,250 g/m2
Air doctor blade: 5 – 60 g/m2

Viscosity
Paste (1000): 100 – 50,000 mPas
Foam: 10,000 – 25,000 mPas
Air doctor blade: 5 – 10,000 mPas













Double side doctor blade system

Coatema Double knife system II RGB

Coating
Doctor blade: 10 – 1,250 g/m2
Air doctor blade: 5 – 60 g/m2

Viscosity
Paste (1000): 100 – 50,000 mPas
Foam: 10,000 – 25,000 mPas
Air doctor blade: 5 – 10,000 mPas







Case doctor blade

Coatema Chamber knife system RGB

Coating
2 – 200 g/m2

Viscosity
1 – 15,000 mPas









Commabar

Coatema Commabar system RGB

Coating
Air doctor blade: 5 – 1,250 g/m2

Viscosity
Paste: 5 – 60 mPas
Foam: 10,000 – 25,000 mPas













Reverse Commabar

Coatema Reverse commabar system RGB

Coating
Air doctor blade: 2 – 200 g/m2

Viscosity
Paste: 1 – 15,000 mPas









Slot die

Coatema Slot die system RGB

Coating
<1 – 200 g/m2

Viscosity
1 – 30,000 mPas













Slot die (curtain coating)

Coatema Rotary screen system RGB

Coating
10 – 300 g/m2

Viscosity
10,000 – 80,000 mPas





















Foulard

Coatema Dipping system RGB

Coating
Depending on the textile

Viscosity
1 – 10,000 mPas















Powder scattering

Coatema Powder scattering system RGB

Coating
10 – 300 g/m2

Viscosity
Application of powdery materials



















Micro roller

Coatema Microroller system RGB

Coating
2 – 100 g/m2

Viscosity
1 – 15,000 mPas









2-roller system

Coatema 2 Roller system RGB

Coating
2 – 100 g/m2

Viscosity
1 – 10,000 mPas











3-roller system

Coatema 3 Roller system RGB

Coating
2 – 200 g/m2

Viscosity
1 – 15,000 mPas









5-roller system

Coatema 5 Roller system RGB

Coating
<1 – 10 g/m2

Viscosity
1 – 15,000 mPas









Reverse roll coater

Coatema Reverse roll system RGB

Coating
2 – 500 g/m2

Viscosity
100 – 50,000 mPas





















Our common printing systems are:



Gravure printing system

Coatema Engraved roller system RGB

Variation of the coating weight
2 – 200 g/m2

Viscosity
1 – 15,000 mPas









Gravure printing system (with chamber blade)

Coatema Gravure roller system RGB

Variation of the coating weight
2 – 100 g/m2

Viscosity
1 – 10,000 mPas













Indirect gravure printing sytem

Coatema Gravure indirect system RGB

Variation of the coating weight
2 – 500 g/m2

Viscosity
1 – 15,000 mPas























Flexo printing system

Coatema Flexography system RGB

Variation of the coating weight
2 – 200 g/m2

Viscosity
1 – 15,000 mPas







Nanoimprinting system

Coatema Nanoimprinting system RGB

Variation of the coating weight
2 – 200 g/m2

Viscosity
1 – 15,000 mPas







Inkjet printing system

Coatema Inkjet system RGB2

Variation of the coating weight
2 – 200 g/m2

Viscosity
1 – 15,000 mPas
